Tipper Semi Trailer

A tipper semi trailer, also known as a dump semi trailer or a tipping trailer, is a type of trailer designed specifically for transporting and unloading loose bulk materials, such as sand, gravel, and construction debris. It is commonly used in the construction, mining, and agricultural industries.

Product Name: Tipper Semi Trailer

Price:Direct factory. Order now and get 10% off

Different Parameters, Different Price

Contact us for more infos. Whatsapp/Tel: +86 18615520624

Email: sales@vehiclemaster.com

Contact Now

Product Details

Tipper semi trailer implements most fulfilling manufacture technology, applies computerized submerged-arc welding for vertical beam and shot blasting therapy for the frame, receives rid of welding stress effectively, makes use of gold standard equipment and science all thru the entire manufacturing approach to make positive formation and assembly accuracy.

Tipper Semi Trailer

Video of Tipper Semi Trailer

Specification of Tipper Semi Trailer

Item	Specification
Brand	Vehicle Master
Application	Coal/Mine/Stand/Stone Loading
Dump Style	Rear Dump
Loading Capacity	30T-100T
Axle	2/3/4*13/16T VEHICLE MASTER/FUWA/BPW
Length	11000mm
Width	2500mm
Height	2800mm
Cylinder	HYVA (model is according to the length of cargo box)
Floor Plate Thickness	5mm
Cargo Thickness	4mm
Cargo Style	Rectanglular/Round
Front Axle Lifting	Available
Main Beam	Material Q345/T700
	Height: 500mm
	Upper Plate: 14mm
	Middle Plate: 8mm
	Lower Plate: 16mm
Tire	11.00R20/12R222.5*8/12/16 pieces Linglong/Triangle/Double-Coin/Bridgestone
Rim	8.0/9.0*8/12/16 pieces, steel/aluminum
Suspension	Mechanical/Airbag
Leaf Spring	90mm13/16mm10 pieces
Landing Gear	28T two-speed, JOST
King Pin	#50(2")/#90(3.5"), JOST/Other Brand
Tool Box	Steel/aluminum

Details of Tipper Semi Trailer

Three coats of paint, high quality circuit.

High load low weight suspension with optional air suspension.

28T linkage landing gear is available in a variety of specifications and materials.

Product Advantage

U section box:

U model box design and analysis, larger section area with lower barycentre, load more and unloading easier, saftly and efficiently

Material：

Hardox 450 or equal wear and abrasion-resistant material box, T700 high tension beam, tare weight lighter 2000kg than normal material tipper, longer service time and lower fuel consumption

Cylinder：

FC and FE model optional, higher operating pressure, help Max 45° tilt angle, reducing turnaround time with faster-ripping speed, increasing operating time with long service intervals

Fasten Sys：

Rear door auto fasten lock efficiency work, adjustable design keep suitable situation,easy maintenance and replace
